Advanced Usage Guide¶

Comprehensive guide to advanced NeuroScope features, customization options, and best practices for neural network development.

Architecture Design¶

Layer Configuration¶

from neuroscope import MLP

# Basic architecture
model = MLP([784, 128, 64, 10])

# Advanced configuration
model = MLP(
    layer_dims=[784, 256, 128, 64, 10],
    hidden_activation="leaky_relu",
    out_activation="softmax",
    init_method="smart",           # Auto-selects best initialization
    dropout_rate=0.3,
    dropout_type="normal",         # default (alpha)for SELU networks
)

model.compile(
    optimizer='adam',
    lr=0.001,
    reg=None,                      # l2 for reg to work
    lamda=0.01,                    # regularization impact
    gradient_clip=None             # gradient clip norm
)

Activation Function Selection¶

# Available activation functions
activations = {
    "relu": "Standard ReLU - good default choice",
    "leaky_relu": "Leaky ReLU - prevents dead neurons",
    "selu": "SELU - self-normalizing, use with selu_init",
    "tanh": "Hyperbolic tangent - symmetric, zero-centered",
    "sigmoid": "Sigmoid - for binary classification output"
}

# Use SELU for deep networks
deep_model = MLP(
    [784, 512, 256, 128, 64, 10],
    hidden_activation="selu",
    init_method="selu_init",       # Specialized initialization for SELU
    dropout_type="alpha"           # Alpha dropout maintains self-normalization
)

Training Configuration¶

Optimizer Selection¶

# Adam (default) - adaptive learning rate with momentum
model.compile(optimizer="adam", lr=1e-3)

# SGD - stochastic gradient descent
model.compile(optimizer="sgd", lr=1e-2)

# Note: NeuroScope currently supports "adam" and "sgd" optimizers
# Adam uses built-in beta1=0.9, beta2=0.999, eps=1e-8 parameters

Regularization Options¶

# L2 regularization
model.compile(optimizer="adam", lr=1e-3, reg="l2", lamda=0.01)

# Gradient clipping
model.compile(optimizer="adam", lr=1e-3, gradient_clip=5.0)

# Combined regularization
model.compile(
    optimizer="adam",
    lr=1e-3,
    reg="l2",
    lamda=0.001,
    gradient_clip=1.0
)

Dropout Configuration¶

# Standard dropout during model creation
model = MLP(
    [784, 128, 64, 10],
    hidden_activation="relu",
    dropout_rate=0.3,           # 30% dropout
    dropout_type="normal"       # Standard dropout
)

# Alpha dropout for SELU networks
model = MLP(
    [784, 128, 64, 10],
    hidden_activation="selu",
    dropout_rate=0.1,
    dropout_type="alpha"        # Alpha dropout maintains normalization
)

Advanced Diagnostics¶

Pre-Training Analysis¶

from neuroscope.diagnostics import PreTrainingAnalyzer

analyzer = PreTrainingAnalyzer(model)
# prints a beautiful summary report
analyzer.analyze(X_train, y_train)

Post-training Evaluation¶

from neuroscope.diagnostics import PostTrainingEvaluator

evaluator = PostTrainingEvaluator(model)

# Robustness testing
robustness = evaluator.evaluate_robustness(X_test, y_test,
                                         noise_levels=[0.01, 0.05, 0.1, 0.2])
print(f"Overall robustness: {robustness['overall_robustness']:.3f}")
print(f"Status: {robustness['status']}")

# Performance evaluation
performance = evaluator.evaluate_performance(X_test, y_test)
print(f"Test accuracy: {performance['accuracy']:.3f}")
print(f"Samples per second: {performance['samples_per_second']:.0f}")
print(f"Total parameters: {performance['total_params']}")

# Stability evaluation
stability = evaluator.evaluate_stability(X_test, y_test, n_samples=100)
print(f"Prediction stability: {stability['overall_stability']:.3f}")

# Comprehensive evaluation report
evaluator.evaluate(X_test, y_test)

Real-Time Training Monitoring¶

from neuroscope.diagnostics import TrainingMonitor

# Configure monitoring
monitor = TrainingMonitor()

# Train with monitoring
history = model.fit(
    X_train, y_train,
    X_val=X_val, y_val=y_val,
    epochs=100,
    monitor=monitor,
    monitor_freq=1,
    early_stopping_patience=10
)

# Monitor provides real-time output during training:
# Epoch   1  Train loss: 0.652691, Train Accuracy: 0.6125 Val loss: 0.6239471, Val Accuracy: 0.64000
# ----------------------------------------------------------------------------------------------------
# SNR: 🟡 (0.70),     | Dead Neurons: 🟢 (0.00%)  | VGP:      🟢  | EGP:     🟢  | Weight Health: 🟢
# WUR: 🟢 (1.30e-03)  | Saturation:   🟢 (0.00)   | Progress: 🟢  | Plateau: 🟢  | Overfitting:   🟡
# ----------------------------------------------------------------------------------------------------


# Ultra-fast training - 10-100x speedup!
history = model.fit_fast(
    X_train, y_train, X_val, y_val,
    epochs=100,
    batch_size=256,
    eval_freq=5
)

Advanced Visualization¶

Comprehensive Training Analysis¶

from neuroscope.viz import Visualizer

viz = Visualizer(history)

# Learning curves with confidence intervals
viz.plot_learning_curves(
    figsize=(9, 4),
    ci=True,                      # Confidence intervals
    markers=True,                 # Show epoch markers
    save_path="learning_curves.png"
)

# Dynamic metric labeling examples:
# For R² regression: Shows "R²" instead of "Accuracy"
# For F1 classification: Shows "F1" instead of "Accuracy"
# For precision: Shows "Precision" instead of "Accuracy"
# The system automatically detects your training metric and updates all labels

# Network internals evolution over epochs
viz.plot_activation_stats(
    figsize=(12, 4),
    reference_lines=True          # Show healthy ranges
)

viz.plot_gradient_stats(
    figsize=(12, 4),
    reference_lines=True
)

viz.plot_weight_stats(
    figsize=(12, 4),
    reference_lines=True
)

# Distribution plots for specific epochs
viz.plot_activation_hist(epoch=25, figsize=(9, 4), kde=True)
viz.plot_gradient_hist(epoch=25, figsize=(9, 4), kde=True)
viz.plot_weight_hist(epoch=25, figsize=(9, 4), kde=True)

# Gradient norms and weight update ratios
viz.plot_gradient_norms(figsize=(12, 4), reference_lines=True)
viz.plot_update_ratios(figsize=(12, 4), reference_lines=True)

Training Animation with Dynamic Labels¶

# Create animated training visualization with correct metric labels
viz.plot_training_animation(bg="dark", save_path="training_animation.gif")

# The animation automatically shows:
# - "Accuracy Evolution" for accuracy metrics
# - "R² Evolution" for R² regression
# - "F1 Evolution" for F1 score
# - "Precision Evolution" for precision
# - And updates all bar chart labels accordingly

Best Practices¶

Model Architecture Guidelines¶

# For deep networks (>4 layers)
deep_model = MLP(
    [784, 512, 256, 128, 64, 32, 10],
    hidden_activation="selu",      # Self-normalizing
    init_method="selu_init",       # Proper initialization
    dropout_type="alpha",          # Maintains normalization
    dropout_rate=0.1
)
deep_model.compile(optimizer="adam", lr=1e-3, reg="l2", lamda=1e-4)

# For wide networks
wide_model = MLP(
    [784, 1024, 1024, 10],
    hidden_activation="relu",
    init_method="he",
    dropout_rate=0.5              # Higher dropout for wide networks
)
wide_model.compile(optimizer="adam", lr=1e-3, reg="l2", lamda=1e-5)

# For small datasets
small_data_model = MLP(
    [784, 64, 32, 10],
    hidden_activation="tanh",      # Less prone to overfitting
    dropout_rate=0.2
)
small_data_model.compile(optimizer="adam", lr=1e-3, reg="l2", lamda=1e-3)

Troubleshooting¶

Common Issues and Solutions¶

Issue	Symptoms	Solutions
Vanishing Gradients	Loss plateaus early, poor learning	Use ReLU/LeakyReLU, He initialization, lower learning rate
Exploding Gradients	Loss becomes NaN, unstable training	Gradient clipping, lower learning rate
Dead Neurons	Many zero activations	LeakyReLU, better initialization, check learning rate
Overfitting	Training accuracy >> validation accuracy	Dropout, L1/L2 regularization, more data
Underfitting	Both accuracies low	Larger network, lower regularization, higher learning rate

Recipe Book¶

Quick Problem Solver¶

This comprehensive reference helps you quickly identify and solve common neural network training issues using NeuroScope’s diagnostic tools.

Dead Neurons (ReLU Death)¶

Symptoms:

🔴 Dead Neurons > 30% in TrainingMonitor
Activations stuck at zero
Poor learning performance

Causes:

Large learning rates
Poor weight initialization
Saturated ReLU activations

Solutions:

# Use Leaky ReLU instead of ReLU
model = MLP([784, 128, 10], hidden_activation="leaky_relu")

# Better initialization
model = MLP([784, 128, 10], init_method="he")

# Lower learning rate
model.compile(optimizer="adam", lr=1e-4)

# Gradient clipping
model.compile(optimizer="adam", lr=1e-3, gradient_clip=1.0)

NeuroScope Tools:

TrainingMonitor: Real-time dead neuron detection
PreTrainingAnalyzer: Weight initialization validation
Visualizer.plot_activation_hist(): Activation distribution analysis

Vanishing Gradient Problem (VGP)¶

Symptoms:

🔴 VGP status in TrainingMonitor
Gradient Signal-to-Noise Ratio < 0.4
Early layers learn slowly

Causes:

Deep networks with sigmoid/tanh
Poor weight initialization
Inappropriate activation functions

Solutions:

# Use ReLU-based activations
model = MLP([784, 256, 128, 64, 10], hidden_activation="relu")

# He initialization for ReLU
model = MLP([784, 256, 128, 64, 10], init_method="he")

# For very deep networks, use SELU
model = MLP([784, 512, 256, 128, 64, 32, 10],
           hidden_activation="selu", init_method="selu_init")

NeuroScope Tools:

TrainingMonitor: Real-time VGP detection
Visualizer.plot_gradient_stats(): Gradient magnitude tracking
Visualizer.plot_gradient_hist(): Gradient distribution analysis

Exploding Gradient Problem (EGP)¶

Symptoms:

🔴 EGP status in TrainingMonitor
Loss becomes NaN or very large
Unstable training dynamics

Causes:

High learning rates
Deep networks without normalization
Poor weight initialization

Solutions:

# Gradient clipping (most effective)
model.compile(optimizer="adam", lr=1e-3, gradient_clip=1.0)

# Lower learning rate
model.compile(optimizer="adam", lr=1e-4)

# Better initialization
model = MLP([784, 128, 10], init_method="xavier")

NeuroScope Tools:

TrainingMonitor: Real-time EGP detection
Visualizer.plot_gradient_norms(): Gradient norm monitoring

Activation Saturation¶

Symptoms:

🔴 Saturation > 25% in TrainingMonitor
Sigmoid/Tanh outputs near 0 or 1
Poor gradient flow

Causes:

Sigmoid/Tanh with large inputs
Poor weight initialization
High learning rates

Solutions:

# Use ReLU-based activations
model = MLP([784, 128, 10], hidden_activation="relu")

# For sigmoid/tanh, use proper initialization
model = MLP([784, 128, 10], hidden_activation="tanh", init_method="xavier")

# Lower learning rate
model.compile(optimizer="adam", lr=1e-4)

NeuroScope Tools:

TrainingMonitor: Real-time saturation monitoring
Visualizer.plot_activation_hist(): Activation distribution analysis

Poor Weight Update Ratios¶

Symptoms:

🔴 WUR outside 1e-4 to 1e-2 range
Very slow or unstable learning

Causes:

Inappropriate learning rate
Poor weight initialization
Gradient scaling issues

Solutions:

# Adjust learning rate based on WUR
# If WUR < 1e-4: increase learning rate
model.compile(optimizer="adam", lr=1e-2)

# If WUR > 1e-2: decrease learning rate
model.compile(optimizer="adam", lr=1e-4)

# Use adaptive learning rate
model.compile(optimizer="adam", lr=1e-3)  # Adam adapts automatically

NeuroScope Tools:

TrainingMonitor: Real-time WUR monitoring
Visualizer.plot_update_ratios(): Update ratio tracking

Training Plateau¶

Symptoms:

🔴 Plateau status in TrainingMonitor
Loss stops decreasing
No learning progress

Causes:

Learning rate too low
Local minima
Insufficient model capacity

Solutions:

# Increase learning rate
model.compile(optimizer="adam", lr=1e-2)

# Add regularization to escape local minima
model.compile(optimizer="adam", lr=1e-3, reg="l2", lamda=1e-4)

# Increase model capacity
model = MLP([784, 256, 128, 10])  # Larger hidden layers

NeuroScope Tools:

TrainingMonitor: Real-time plateau detection
Visualizer.plot_learning_curves(): Loss progression analysis

Overfitting¶

Symptoms:

🔴 Overfitting status in TrainingMonitor
Validation loss increases while training loss decreases
Large gap between train/validation accuracy

Causes:

Model too complex
Insufficient regularization
Too many training epochs

Solutions:

# Add L2 regularization
model.compile(optimizer="adam", lr=1e-3, reg="l2", lamda=1e-3)

# Add dropout
model = MLP([784, 128, 10], dropout_rate=0.3)

# Early stopping
history = model.fit(X_train, y_train, X_val=X_val, y_val=y_val,
                   early_stopping_patience=10)

# Reduce model complexity
model = MLP([784, 64, 10])  # Smaller hidden layers

NeuroScope Tools:

TrainingMonitor: Real-time overfitting detection
PostTrainingEvaluator: Comprehensive overfitting analysis
Visualizer.plot_learning_curves(): Train/validation gap visualization

Poor Initial Loss¶

Symptoms:

PreTrainingAnalyzer shows FAIL status
Initial loss much higher than expected
Training starts poorly

Causes:

Poor weight initialization
Data preprocessing issues
Wrong output activation

Solutions:

# Check and fix weight initialization
analyzer = PreTrainingAnalyzer(model)
analyzer.analyze()
model = MLP([784, 128, 10], init_method="smart")

# Verify output activation
# For binary classification:
model = MLP([784, 128, 1], out_activation="sigmoid")
# For multiclass:
model = MLP([784, 128, 10], out_activation="softmax")
# For regression:
model = MLP([784, 128, 1], out_activation=None)

NeuroScope Tools:

PreTrainingAnalyzer: Comprehensive pre-training validation
PreTrainingAnalyzer.analyze(): Pre training analysis

Poor Model Robustness¶

Symptoms:

PostTrainingEvaluator shows poor robustness
Model fails on noisy inputs
Unstable predictions

Causes:

Overfitting to training data
Insufficient regularization
Poor generalization

Solutions:

# Add noise-based regularization
model = MLP([784, 128, 10], dropout_rate=0.2)

# Increase regularization
model.compile(optimizer="adam", lr=1e-3, reg="l2", lamda=1e-3)

# Data augmentation (add noise during training)
# Note: Implement in your training loop

NeuroScope Tools:

PostTrainingEvaluator.evaluate_robustness(): Noise robustness testing
PostTrainingEvaluator.evaluate_stability(): Prediction stability analysis

Quick Reference Table¶

Problem	TrainingMonitor Status	Primary Solution	NeuroScope Tool
Dead Neurons	🔴 Dead Neurons > 30%	Use LeakyReLU, He init	`plot_activation_hist()`
Vanishing Gradients	🔴 VGP, SNR < 0.4	ReLU + He init	`plot_gradient_stats()`
Exploding Gradients	🔴 EGP	Gradient clipping	`plot_gradient_norms()`
Saturation	🔴 Saturation > 25%	Avoid sigmoid/tanh	`plot_activation_hist()`
Poor WUR	🔴 WUR outside range	Adjust learning rate	`plot_update_ratios()`
Plateau	🔴 Plateau	Increase LR or capacity	`plot_learning_curves()`
Overfitting	🔴 Overfitting	Add regularization	`evaluate_robustness()`

Next Steps¶

Technical Deep Dive: Research-backed explanations with mathematical foundations and literature citations
API Reference: Explore all available functions and classes
Examples: Jupyter notebooks with real-world examples
Quickstart Guide: Quick introduction to NeuroScope
Contributing: Help improve NeuroScope
